HMP80 Hydraulic solenoid directional monoblock control valve

Brand :Zhongyuan

Product origin :China

Delivery time :20 days

Supply capacity :10000 PCS per month


80l/min P80 Series Hydraulic Solenoid Operated Directional Control Valves

The monoblock directional control valves-solenoid operated, offer perfect choice whether you are designing a new system or just simply trying to get more out of your current system. With two special spools and 6 different monoblock housings these valves can meet the specific needs of your application and hydraulic schemes by their double acting in 3 positions A and D spools.


Nom.Pressure

MPa

Max.Pressure

MPa

Nom.Flow rate

L/min

Max.Flow rate

L/min

Back Pressure

MPa

Hydraulic Oil

Tem.rang

Visc.rang

mm2/S

Filtrating Accuracy

μm

20

31.5

80

80

1

-20+80

10400

10


Standart Code

Code

Number of spools

Nominal flow rate
L/min

Max. pressure
P port
bar

Voltage
V

P80-A-ES3-12VDC/24VDC-G

1

80

250

12/24

P80-AA-ES3-12VDC/24VDC-G

2

80

250

12/24

P80-AAA-ES3-12VDC/24VDC-G

3

80

250

12/24

P80-AAAA-ES3-12VDC/24VDC-G

4

80

250

12/24

P80-AAAAA-ES3-12VDC/24VDC-G

5

80

250

12/24

P80-AAAAAA-ES3-12VDC/24VDC-G

6

80

250

12/24
